Lowering of 2004 V5 Bora

[Hairy_mic]

I am currently considering lowering my v5, just wondered how easily this can be achieved.
can this be done without adversely affecting tire wear etc?
I am looking at steel sump guards at the moment, as i think this is a crucial step for the bora.

as far as lowering, im not looking for anything too drastic, maybe look at puttin 18" on.


if there is a sticky or post on this already id appreciate a linky,

[grtuned]

Lowering of 2004 V5 Bora

Easiest way to go is using lowered springs say 20-30mm
Then If you wanted more control over the suspension I'd recommend coilovers. Many different types to choose from its all up to you how much your willing to spend. Check out ebay.

[CPITUNING]

To make your life easier we have the appropriate kit for your car: Volkswagon (VW) Blueline Coilover Kits | SlickOnline - AutoSlick & HomeSlick

We would be more than happy to help you out with this.

- Joe

[Hairy_mic]

To make your life easier we have the appropriate kit for your car: Volkswagon (VW) Blueline Coilover Kits | SlickOnline - AutoSlick & HomeSlick

We would be more than happy to help you out with this.

- Joe

Im sure coilies would be the go, how does this affect camber etc?

[dylan8]

Im sure coilies would be the go, how does this affect camber etc?

Doesnt.

Rear of the car stays basically the same. Even if you slam it the camber stays at factory 1-1.5deg, toe-in increases ever so slightly due to the rolling beam, but its not enough to cause excessive wear.
Front just needs an alignment after everything as settled in, again camber doesn't move much.

There are other things to take into account through...
Be sure to get new strut top bearings and bushes.
depending on ks on the car, new control arm bushes might be worth doing at the same time pre alignment.
Another thing to think about is the FWD sway bar problem. if you do some research you will see mk4s with a 30-50mm + drop will have issues with the sway bar rubbing on the drive-shafts. There are a number of options to sort this (longer/shorter end links, after market sway bar, or, removing the bar completely), its up how much you lower the car and personal preference to which path you go down

[Hairy_mic]

Lowering of 2004 V5 Bora

Is it worth sorting the read toe in? What's the cheapest way of achieving this?


Sent from my iPhone using Tapatalk

[Hairy_mic]

Lowering of 2004 V5 Bora

Tbh I'd be dropping prob only 25mm all round


Sent from my iPhone using Tapatalk

[dylan8]

Tbh I'd be dropping prob only 25mm all round


Sent from my iPhone using Tapatalk

most likely wont have issues with the sway then.
just get a standard alignment on the front after the springs have settled in.
there is enough moment in the ball joint and tie rods to fix any changes

[RolfGolf]

Keep in mind that your standard suspension will have dropped over time, so what you think of as a 25mm drop might not lower the car as much as you expect.

[Brisbane's Bora]

I have done pretty much no supporting mods to my v5 and have never had a problem, have only replaced a few old rubber bits and pieces at install and have had an alignment. No skid plates/sump guard either though if I were to go much lower I would probably want something.

Also, get coilovers

[skatz]

Im also looking for more low on my car will this end link help me get around the sway bar issue?

Volkswagen Golf IV 1.8T > ES#2063803 Stainless Steel Adjustable Sway Bar End Link Set - ECS006001

[dylan8]

Im also looking for more low on my car will this end link help me get around the sway bar issue?

Volkswagen Golf IV 1.8T > ES#2063803 Stainless Steel Adjustable Sway Bar End Link Set - ECS006001

Depends on how low. results seem to vary

[xpeesx]

To make your life easier we have the appropriate kit for your car: Volkswagon (VW) Blueline Coilover Kits | SlickOnline - AutoSlick & HomeSlick

Does anyone run these 'blueline' coilovers on here? Interested to know what they are like.

[Brisbane's Bora]

Re: Lowering of 2004 V5 Bora

I do, they haven't failed me in coming up on 30000kms, they go really low and can take a bit of punishment but they are quite bouncy. Great for how much they cost but I am almost considering upgrading mine atm

Sent from my Galaxy Nexus using Tapatalk 2
